Vision+ N3

Certified NDI®HX3 Auto Tracking Live Streaming PTZ Camera

NDI®HX3: Enhanced Performance & Lower Latency for Live Production

NDI®HX3 brings better quality and lower latency to video production, supporting H.264/H.265 compression for flexibility and performance. With NDI®HX3 certification, Vision+ N3 series provide superior video quality with minimal latency, ensuring smooth and professional live productions. The optimized low latency of NDI®HX3 enhances real-time transmission, making it perfect for dynamic and interactive content creation.

NDI®HX2

NDI®HX3

1080p60 FHD Resolution

Equipped with premium image processing solution and Sony CMOS sensor, Vision+ N3 delivers FHD and crystal-clear images even in low-light working environments.

NDI®HX3/3G-SDI/HDMI/USB 2.0 Available

In addition to NDI®HX3, Vision+ N3 simultaneously outputs images via 3G-SDI, HDMI, and USB 2.0. 3G-SDI and HDMI are for transitional video production, while the USB output can function as a high-end webcam.
Note: USB and NDI cannot output simultaneously.

FreeD Integration Unlocks Immersive Virtual Productions

FreeD is a protocol that enables precise transmission of Pan, Tilt, Zoom, and Focus (PTZF) data directly from the camera to tracking system. Widely supported by most virtual set systems, FreeD makes virtual productions easier than ever. The Vision+ N3 seamlessly integrates FreeD technology, empowering users to explore dynamic shooting angles and perspectives, ideal for versatile real-world and virtual-world applications. Vision+ N3’s broad compatibility with industry-leading virtual set systems like Brainstorm, Vizrt, Zero Density, Aximmetry, Unreal Engine, and VSet3D ensures a smooth workflow for all your virtual production needs.

Before

After

Tally Lights for Effortless Production Cues

Tally light, a visible indicator typically in red LED, illuminates to signal when the camera is live and actively feeding its image output.

Vision+ N3 series features built-in tally lights that work with NDI. This intuitive feature receives signals directly from NDI, without the need for separate tally control systems. A bright LED illuminates to clearly indicate which camera is currently on-air (“Program”) and which is lined up for the next transition (“Preview”).

3.5mm Stereo Line-in

The Vision+ N3 features a 3.5mm stereo line-in audio interface, allowing for direct connection of external audio sources. This ensures high-quality, synchronized audio alongside your video feed, enhancing overall production quality. The line-in supports various audio devices, providing flexibility and convenience for professional broadcasting and video production.

20X/30X Optical Zoom

The Vision+ N3 provides 20X optical zoom with a 60° FOV and 30X optical zoom with a 63° FOV. Its advanced focusing algorithm ensures rapid and accurate focus even during zoom or movement.

Seamless Camera Setup with SSDP

Setting up your Telycam PTZ camera has never been easier, thanks to SSDP integration. This feature streamlines the process of finding your camera’s IP address, especially under multi-camera streaming, eliminating the need for complicated searches or additional tools. Simply connect your camera with an Ethernet cable, ensuring it’s on the same local network with your computer.

Telycam + Iris: Take Your Camera to the Cloud

With Iris integrated, your Telycam Vision+ N3 camera goes fully cloud-connected — accessible and controllable from any browser, anywhere. Connect in just two clicks to unlock remote PTZ control, AI auto-tracking, framing, and centralized management — all in one simple interface.

Iris integration is supported on units shipped after January, 1st, 2026.

Native AI-Based Auto-Tracking

The Vision+ N3 features AI-based auto-tracking, automatically following subjects to enhance ease of use and capture the moments flawlessly.

Specifications

Camera

	Vision+ N3 20x	Vision+ N3 30x
Part No.	TLC-300-IP-20(NDI)-AB	TLC-700-IP-30(NDI)-AB
Sensor	1/2.8" 2.4MP CMOS	1/1.8" 9MP CMOS
Optical Zoom	20x	30x
Lens	f = 4.9 ~ 98mm F1.5 ~ F3	f = 6.91 ~ 214.64mm F1.35 ~ F4.6
Horizontal View Angle	55.8° (Wide) ~ 3.2° (Tele)	63° (Wide) ~ 2.1° (Tele)
Vertical View Angle	32.2° ~ 1.8°	34.14° ~ 1.12°
Diagonal View Angle	61° ~ 3.64°	67.08° ~ 2.27°
Minimum Working Distance	1.0m	1.5m
S/N Ratio	≥50dB

Video Format

HDMI	1920×1080 P60/50/30/25/59.94/29.97/24/23.98 1920×1080 I60/50/59.94 1280×720 P60/50/30/25/59.94/29.97
NDI®\|HX3	Main Stream: 1920×1080 @15~60; 1280×720 @15~60; 1024×576 @15~60 Sub Stream: 640×360 @15~30
3G-SDI	1920×1080 P60/50/30/25/59.94/29.97/24/23.98 1920×1080 I60/50/59.94 1280×720 P60/50/30/25/59.94/29.97
USB Type-C	NV12: 1920×1080 P5; 1280×720 P15; 1024×576 P25; 800×448 P30 YUYV: 1920×1080 P5; 1280×720 P10; 1024×576 P15; 800×448 P30 MJPG: 1920×1080 P30; 1280×720 P30; 1024×576 P30; 800×448 P30 H264/HEVC: 1920×1080 P30; 1280×720 P30; 1024×576 P30; 800×448 P30

Image Parameters

	Vision+ N3 20x	Vision+ N3 30x
Noise Reduction	2D & 3D
Minimum Lux	0.5 Lux (50 IRE, Max AGC, 1/30, F1.5)	0.5 Lux (50 IRE, Max AGC, 1/30, F1.35)
White Balance	Auto / Manual / ATW / Push / Indoor / Outdoor / Color Temperature
Exposure	Auto / Manual / Shutter Priority / Iris Priority / Brightness Priority
Anti-Flicker	OFF, 50Hz, 60Hz
Image Flip	Supported
Mirroring	Supported
Focus	Auto / Manual
Iris	Auto / Manual
Electronic Shutter	Auto / Manual
Gamma	Supported
Backlight Compensation	Supported

IP Streaming

Video Encoding	H.264 / H.265
Bitrate Control	Variable bitrate (VBR), Constant bitrate (CBR)
Bitrate Range	1024Kbps ~ 122800Kbps
Network Port Speed	1000M
Protocol	NDI®\|HX3, SRT, HTTP, RTSP, RTMP, ONVIF, VISCA over IP (TCP & UDP), VISCA, PELCO P/D, SSDP, FreeD, NTP, RTP Multicast, WebRTC

Pan / Tilt Movement

	Vision+ N3 20x	Vision+ N3 30x
Preset	Remote controller: 10; Serial port: 256; Accuracy: 0.1°
Pan Rotation Angle	-170° ~ +170°
Tilt Rotation Angle	-30° ~ +90°
Pan Rotation Speed	0.1° ~ 120°/s	0.1° ~ 80°/s
Tilt Rotation Speed	0.1° ~ 80°/s	0.1° ~ 60°/s

I/O Interface

Control Port	RS232 (RS485), NDI®\|HX3
Video Port	NDI®\|HX3, HDMI, 3G-SDI, USB Type-C
Audio Port	Stereo 3.5mm line in
Tally	Supported
PoE+	Supported
Daisy Chain	Supported

General

	Vision+ N3 20x	Vision+ N3 30x
Input Voltage	DC 12V, PoE+ (IEEE 802.3at)
Operating Temperature	-10°C ~ 50°C
Operating Humidity	≤80%
Dimension (L×W×H)	220 × 190 × 173mm	220 × 190 × 193.5mm
Net Weight	1.5kg (3.3 lbs)	1.9kg (4.2 lbs)
Color	Black / White
